Type: UT-58U/59U

——————————————————————————————————————————————————————————————————-

Material Code

Component Seals

Equivalent to:

O-ring Mounted Mechanical Seals

● AESSEAL M03S

● VULCAN 1659S

● EAGLE BURGMANN BT-C5.KU

● JOHN CRANE 58U

● STERLING 259S

Rubber Bellows Mechanical Seals

Wedge Ring Mechanical Seals

PTFE Bellows Mechanical Seals

Metal Bellows Seals

Catridge
Mechanical Seals

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Flygt Pump Seals

* Flygt Pumps Models List

Common Pumps Seals

Operating Limits:

Grundfos / CNP

Xylem

● Temperature: -20℃ - +220℃

● Pressure：≤ 18bar

● Speed: ≤ 25m/s

● Shaft Size: 14mm - 100mm

_ _ _ _ _ __ _ _ _ __ _ _ _ _ _ _ _ _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ _ _ _

Wilo-EMU

Hidrostal

__ _ _ _ __ _ _ _ __ _ _ __ _ _ _ __ __ _ _ __ _ _ _ _ _ _

Assembly Dwg:

Lowara

Materials:

Seal Parts & Related Products

Springs

● Seal Rings: A,B,Q1/12,Q2/22,

U1/12,U2/22

● Elastomer: E,K,N,P,S,V,X

● Metal Part: F,G,M5,S6

RBSIC Seal Rings

SSIC Seal Rings

Tungsten Carbide Seal Rings

Carbon Seal Rings

O-rings

__ _ _ _ __ _ _ _ __ _ _ __ _ _ _ __ __ _ _ __ _ _ _ _ _ _

Encapsulated O-rings / FEP O-rings

Kalrez® O-rings

Chemraz® O-rings

Dimension (mm):

_ _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

D	D3	D4	L1K	L3	D6	D7
14	24	26	35	23	21	25
16	26	28	35	23	23	27
18	32	34	37.5	24	27	33
20	34	36	37.5	24	29	35
22	36	38	37.5	24	31	37
24	38	40	40	26.7	33	39
25	39	41	40	27	34	40
28	42	44	42.5	30	37	43
30	44	46	42.5	30.5	39	45
32	46	48	42.5	30.5	42	48
33	47	49	42.5	30.5	42	48
35	49	51	42.5	30.5	44	50
38	54	58	45	32	49	56
40	56	60	45	32	51	58
43	59	63	45	32	54	61
45	61	65	45	32	56	63
48	64	68	45	32	59	66
50	66	70	47.5	34	62	70
53	69	73	47.5	34	65	73
55	71	75	47.5	34	67	75
58	78	83	52.5	39	70	78
60	80	85	52.5	39	72	80
63	83	88	52.5	39	75	83
65	85	90	52.5	39	77	85
68	88	93	52.5	39	81	90
70	90	95	60	45.5	83	92
75	95	104	60	45.5	88	97
80	104	109	60	45	95	105
85	109	114	60	45	100	110
90	114	119	65	50	105	115
95	119	124	65	50	110	120
100	124	129	65	50	115	125
